BFT115

BFT115

HIGH POWER

Our 115 hp four stroke outboard is an in-line 4 cylinder, with a DOHC 16 valve design, creating a compact and powerful engine. The BFT 115hp includes dual stage induction for improved performance and Lean Burn control for better fuel economy while at cruising speeds. This motor also features Maximum Acceleration System, which improves acceleration at low speeds. A quick movement of the throttle control activates the Maximum Acceleration System, advancing the ignition curve quickly. This will greatly improve “Hole Shot”. With on board warning systems such as low oil pressure, overheat, low battery warning, start in gear protection and over-rev limiter, the Tohatsu 115 hp four stroke engine gives you peace of mind while on the water.

Tohatsu 115 hp 4-Stroke Benefits

  • High output alternator produces 30 amps of power at 1,000 rpms and 40 amps at 2,000+ rpms
  • Available in 20” & 25” shaft lengths
  • In-line 4 cylinder for excellent performance and sleek design
  • Double sealed multi-layered paint process to help protect against corrosion
  • Ultra-low 3 star CARB emission approved
  • 5 Year limited warranty

4-Stroke Technology

  • Dual stage induction for improved performance
  • Lean burn control for better fuel economy at cruising speeds
  • Maximum Acceleration System helps to deliver an exceptional hole shot
  • 3-way cooling system to help protect against overheating
  • Non-linear rubber mounts provide smoother operation at all engine speeds
  • A crankshaft-driven trochoid oil pump ensures long-term durability of critical engine components
  • Optimized fuel injection delivers the precise amount of fuel/air to each cylinder

Fundamentals for User Convenience and Reliability

  • Through the prop exhaust for a quieter ride
  • Built-in freshwater flushing system for easy routine flushing
  • Sealed starter motor that is inverted into a sealed chamber to help protect vital components against elements
  • Electronic Control Module protocols allow engine data to be interfaced with on-board systems and systems displays, such as SONAR or GPS

Warning & Protection

  • Low oil pressure warning
  • Overheat warning
  • Low battery voltage warning
  • Water in fuel warning
  • Start-in-gear protection
  • Over-rev. limiter

FEATURES

4-front Corrosion Protection System

A patented, “Double Sealed” multi-layered paint process, sacrificial anodes and stainless steel technology, along with waterproof connectors, all enhance corrosion protection.

SPECIFICATIONS

Engine (No. of Cylinder)4 Cylinder DOHC 16 Valves
Output115 hp (85.8 kw)
Displacement2,354 cc (143.6 cu.in.)
Bore x Stroke87 x 99 mm (3.4 x 3.9 in)
StartingElectric
Control TypeRemote Control
Gear ShiftForward – Neutral – Reverse
Gear Ratio2.14:1
Ignition SystemMicroComputer Programmed
Transom Height20″, 25″
FuelUnleaded Gasoline (87 Octane) or higher
Oil TypeNMMA Certified FC-W® 4-stroke oil** SAE 10W-30 (SF, SG, SH, SJ)
Oil Capacity1.8 gal. (6.7L) with filter
Weight*478 lbs. (217 kg)
Alternator Output12V, 480W, 55A
Max. RPM Range4,500 – 6,000
Programmed Fuel InjectionStandard
Digital CD Ignition SystemStandard
Start In Gear ProtectionStandard
Thermostat Controlled Cooling SystemStandard
Through-The-Prop ExhaustStandard
Overheat BuzzerStandard
Power Trim and TiltStandard
Oil Pressure WarningStandard
* Weight specification is based on the lightest version.
** FC-W® is a registered trademark of the National Marine Manufacturers Assoc. (NMMA)
Specifications and descriptions are subject to change without notice.
ModelMSRPShaft LengthCylindersElectric StartRemote ControlPower
Trim &Tilt
BFT115ALA$15,987204SSS
BFT115AXA$16,070254SSS
S:Standard
  • MSRP is the “Manufacturer’s Suggested Retail Price” (US$). Actual retail price may vary. Please contact your local dealer for actual retail price.
  • Specifications subject to change without notice. Additional models and/or configurations may be available. Contact your local dealer for details.
