BFT250

BFT250

HIGH POWER

Looking for super power? Our largest, highest horsepower four stroke outboard, the BFT 250 hp, brings a large displacement 3.5 liter V6. This narrow v6 design offers top performance and durability, as well as great fuel economy. The high output alternator provides a 90 amp alternator with 60 charging amps.

Reliability and durability are covered with the 250hp engine’s painted interior cooling passages, providing extra protection against corrosion. Another feature of the 250hp four stroke is the Electronic Control Module. This allows engine data to be interfaced with on-board system displays, such as SONAR or GPS. The BFT 250 hp has another industry-first; separate dual air circuits. This system provides cooler, denser air for better combustion as compared to conventional under-cowl induction systems. Cooler air for your motor, means more horsepower for you!

Tohatsu 250 hp 4-Stroke Benefits

  • High output alternator that produces 90 amp alternator with 60 charging amps
  • Large Displacement 3.5 Litre V6
  • Available in 20”, 25″ & 30” shaft lengths. Standard and Counter rotation
  • Double sealed multi-layered paint process to help protect against corrosion

4-Stroke Technology

  • Dual Stage Induction for improved performance
  • Lean burn control for better fuel economy at cruising speeds
  • Maximum Acceleration System helps to deliver an exceptional hole shot
  • Variable valve timing and lift control
  • 3-Way Cooling System to help protect against overheating
  • Heavy duty 5” diameter gear case built to withstand extreme conditions
  • Non-linear rubber mounts provide smoother operation at all engine speeds
  • A crankshaft-driven trochoid oil pump ensures long-term durability of critical engine components
  • Optimized Fuel Injection delivers the precise amount of fuel/air to each cylinder

Fundamentals for User Convenience and Reliability

  • Through the prop exhaust for a quieter ride
  • Built-in freshwater flushing system for easy routine flushing
  • Separate dual air intake cowling design to help keep your engine’s critical components cool
  • Sealed starter motor that is inverted into a sealed chamber to help protect vital components against elements
  • Electronic Control Module protocols allow engine data to be interfaced with on-board systems and systems displays, such as SONAR or GPS

Warning & Protection

  • Low oil pressure warning
  • Overheat warning
  • Low battery voltage warning
  • Water in fuel warning
  • Start-in-gear protection
  • Over-rev. limiter

FEATURES

Variable Valve Timing and Lift Control

system provides power where and when you need it. This gives you a broader, flatter torque curve and smooth power delivery throughout the engine’s operating range. The result is a superior combination of power, torque and fuel efficiency.

Large Displacement V6

A poweful compact 24 valve Single Overhead Cam [SOHC] design. The narrow V6 design offers top performance and durability as well as great fuel economy.

Separate Dual Air Circuits – Cooler air, more horsepower

The BFT250 has another industry-first; separate dual air circuits. The first is used to cool the engine where air is drawn into the front of engine and circulated around critical engine components. A top mounted cooling fan draws cooling air over the alternator. The second intake circuit directs cooling air from the upper intake vents, separates out moisture, and then inducts it into the throttle body. This system provides for cooler, denser air for better combustion as compared to conventional under-cowl induction systems.

4-front Corrosion Protection System

A patented, “Double Sealed” multi-layered paint process, sacrificial anodes and stainless steel technology, along with waterproof connectors, all enhance corrosion protection.

SPECIFICATIONS

Engine (No. of Cylinder)6 Cylinder SOHC, 60? V6, 24 Valve
Output250 hp (186.4 kw)
Displacement3,583 cc (218.6 cu.in.)
Bore x Stroke89 x 96 mm (3.5 x 3.8 in)
StartingElectric
Control TypeRemote Control
Gear ShiftForward – Neutral – Reverse
Gear Ratio2.00:1
Ignition SystemMicroComputer Programmed
Transom Height20″, 25″, 30″
FuelUnleaded Gasoline (87 Octane) or higher
Oil TypeNMMA Certified FC-W® 4-stroke oil** SAE 10W-30 (SF, SG, SH, SJ)
Oil Capacity2.1 gal. (7.8 L) with filter
Weight*613 lbs. (278 kg)
Alternator Output12V, 720W, 90A
Max. RPM Range5,300 – 6,300
Programmed Fuel InjectionStandard
Digital CD Ignition SystemStandard
Start In Gear ProtectionStandard
Thermostat Controlled Cooling SystemStandard
Through-The-Prop ExhaustStandard
Overheat BuzzerStandard
Power Trim and TiltStandard
Oil Pressure WarningStandard
Variable Valve Timing & Lift ControlStandard
* Weight specification is based on the lightest version.
** FC-W® is a registered trademark of the National Marine Manufacturers Assoc. (NMMA)
Specifications and descriptions are subject to change without notice.
ModelMSRPShaft LengthCylindersElectric StartRemote ControlPower
Trim &Tilt
Counter Rotation
BFT250ALA$25,769206SSS
BFT250AXA$25,863256SSS
BFT250AXCA$26,591256SSSS
BFT250AXXA$26,293306SSS
BFT250AXXCA$27,029306SSSS
S:Standard
  • MSRP is the “Manufacturer’s Suggested Retail Price” (US$). Actual retail price may vary. Please contact your local dealer for actual retail price.
  • Specifications subject to change without notice. Additional models and/or configurations may be available. Contact your local dealer for details.
